General Specs |
| Product Weight (lbs.) | 93 |
| Width (in.) | 22.56 |
| Appliance Color | Gray |
| Depth (in.) | 24.5 |
| Height (in.) | 16 |
| Color | Gray |
| Control Type | Electronic Buttons |
| Amp | 20 |
| Manufacturer Warranty | 1 Year Parts and Labor |
| Cord Length (in.) | 48 |
| Plug Type | NEMA 6-20 |
| Color Finish Name | Light Cool Gray |
| Number Of Cooling Speeds | 3 (cool) / 3 (heat) |
| Air Conditioner Type | Window |
| Maximum CFM | 255 |
| BTU Cooling Rating | 12000 |
| Recommended Room Size | 550 |
| BTU Heat Rating | 10700 |
| Voltage | 230/208 |
| Heater Included | No |
Appearance |
| Color Appearance | Light Cool Gray |
| Installation | EZ Mount |
Capacity |
| Cooling BTUH (MAX) | 18000.0 Btu |
| Heating - Electric - BTUH - AHAM - 1R | 11000/8500 |
| Dehumidification (pts./hr.) | 5.1 |
Economical / Quiet |
| Energy Saver | Yes |
Features |
| Airflow (cfm) Roomside (hi/low) | 435/355 |
| Chassis Type | Slide-Out |
| Delay Timer | 24-Hour On/Off Timer |
| Fan Speed Selections | 3 Cooling 3 Fan Only 3 Heating |
| Filter Type | One Touch Lift-Out |
| Louver Style | 4-Way |
| Mounting Type | EZ Mount |
| Plug Type | Perpendicular / Right Angle / NEMA 6-20P / LCDI |
| Rotary Compressor | Yes |
| Thermostat Type | Electronic |
| Unit Type | Heat / Cool Unit |
| Vent/Air Exchange Exhaust | Top Air Discharge |
| Refrigerant Type | R410A |
| Unit Features | Selectable Thermostat on Remote |
| Airflow Direction | 4-Way Top |
| Area to Cool | 701-1000 |
| Digital Time Temp Display | Yes |
| LCDI / AFCI power cord | Yes |
| Plug Capacity | 230V/20A |
| Power Cord Length | 48" Minimum |
| Product Type | Window |
| Room Air Conditioner Features | Electronic Control, Energy Saver, Heat Mode, On/Off Timer, Remote Control |
Power / Ratings |
| CEER | 10.7/10.7 |
| Sound Level (Low/High) | 60/67 dbA |
| Cooling - Rated Cooling Amps AHAM | 7.5/8.1 |
| Cooling - Watts | 1630/1600 |
| Heating - Electric - Heater Amps | 16.0/15.6 |
| Heating - Electric - Heater Watts | 3500 |
| Heating - Electric - Input Watts | 3630/3020 |
| Voltage (MIN) | 208.0 V |
| Voltage (MAX) | 230.0 V |
Warranty |
| Parts Warranty | Limited 1-year entire appliance |
| Labor Warranty | Limited 1-year entire appliance |
| Warranty Notes | See written warranty for full details |
Weights & Dimensions |
| Depth to Louvers | 9.375 in |
| Grille Depth | 2.0 in |
| Min./Max. Window Opening Width (in.) | 30/39 |
| Minimum Window Opening Height (in.) | 19-1/8 |
| Net Weight | 117.0 lb |
| Overall Depth | 26.3125 in |
| Overall Height | 18.25 in |
| Overall Width | 25.875 in |
